Processing Type:
Plastic Thermoforming Machine
Plastic Type:
PVC, PS, PP, PET
Max.Forming Height(mm):
130 Mm
Forming Width (mm):
780 Mm
Forming Length (mm):
600 Mm
Production Speed(Cycles/min):
35
Video Outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
New Product 2020
Warranty Of Core Components:
1 Year
Core Components:
PLC, Gearbox, Motor, Pressure Vessel, Pump
Air Pressure(MPa):
0.7 MPa
Sheet Thickness(mm):
0.15 - 2 Mm
Heating Power (kW):
40 KW
Air Comsumption(L/min):
2000 L/min
Water Comsumption(L/min):
30 L/min
Condition:
New
Product Type:
Plastic Container
Voltage:
380V
Dimension(L*W*H):
1000*280*300cm
Weight (T):
14 T
Power(KW):
100
Warranty:
1 Year
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Food Shop, Food & Beverage Shops, Machinery
Key Selling Points:
High Productivity
Showroom Location:
None
Application:
Plastic Cup,plastic Egg Tray,blister Packaging,plastic Container,etc
Suitable Material:
PP CPET PS PET PVC OPS PLA
Forming Area:
780*600mm
Sheet Width:
450-810mm
Heating Power:
20-55KW
Travel Depth:
150mm
Max Roll Diameter:
1000mm
Cycle Period:
40/min
After-sales Service Provided:
Video Technical Support, Online Support, Field Maintenance,training
Product Name:
Air Pressure And Vacuum Forming Thermoforming Machine
